MUCKI Tipping Devices
Our MUCKI tipping devices are directly driven systems designed for the safe and controlled emptying of containers at low to medium discharge heights. Thanks to their particularly robust design and modular construction, the tipping devices can be flexibly adapted to a wide range of process environments and container types.
Whether used for feeding conveyors, packaging systems, belt conveyors, or shredders – these tipping devices provide a reliable and ergonomic solution for container handling. Intelligent options such as container clamping or side loading also allow for the seamless integration of demanding automation concepts.
FUNcTION
JOEST tipping devices are designed for the controlled emptying of containers at low to medium discharge heights.
The containers to be emptied are placed in a rugged load-handling attachment, where they are secured either actively or passively. Depending on the configuration, the tipping motion is driven by an electric or hydraulic system, which allows for stepless and precise control of the tipping angle – up to 180°.
Thanks to the flexible container interface, a wide range of container types can be handled – from mesh boxes and laundry carts to custom containers. The units can be loaded from the front or the side, and integration with AGVs (Automated Guided Vehicles), AMRs (Autonomous Mobile Robots), or conveyor systems is also possible.
MUCKI tipping devices stand out for their compact design, high load capacity, and long service life. Optional features include drop height limitation, damped tipping motion, or the direct connection of downstream systems such as chutes, hoppers, or vibratory feeders. This makes them ideal for ergonomic and safe emptying across a broad range of industrial applications.
Product details
- Load capacities up to 5,000 kg
- Tipping angle up to 180° (fixed or continuously adjustable)
- Discharge widths up to 8 meters
- Electric or hydraulic drive
- Compatible with various container types (e.g. mesh boxes, laundry carts, drums)
- MUCKI kinematics for powerful and uniform tipping motion
Options
- Front or side loading possible
- Funnels or chutes can be integrated
- Automatic locking and end position monitoring
- Stainless steel and ATEX-compliant designs for special applications
Fields of Application
JOEST tipping devices are ideal for the controlled, safe, and ergonomic emptying of a wide variety of containers – especially in applications involving medium to heavy loads or requiring precise tipping movements. Thanks to their rugged design and modular configuration, they offer versatile use across a broad range of industries.
Plastic regrind, metal scrap, used tire parts, fluff, shredder feeding, granulator feeding, container loading, chip handling
Aggregates, fiberglass handling
Low-dust tipping, powdery or free-flowing solids in drums or special containers, dryer feeding, rubber, natural rubber, EPS granulate
Melting furnace feeding, feeding of charging cars, aggregates
Feeding of washing centrifuges and deoiling centrifuges
Emptying of parcel containers
Feeding of dough kneaders, low-dust tipping, powdery or free-flowing solids, freeze-dried herbs
Tobacco
Feeding of cold and heat treatment systems, e.g. annealing basket or furnace belt systems
Feeding of surface treatment systems, e.g. galvanizing or phosphating lines
Emptying of octabins
Feeding of washing machines, use in industrial laundries
Equipment Options
Tipping angle up to 180 degrees – steplessly adjustable
Depending on the application, the tipping angle can be flexibly adjusted – from shallow discharge angles to full overhead emptying.
Front or side loading possible
The loading direction can be flexibly adapted to suit system layout and space requirements – also compatible with AGV or conveyor technology.
Funnels or chutes can be integrated
Closed discharge systems such as funnels, chutes, or enclosures can be added as needed.
Gentle tipping motion with drop height damping
For sensitive products or noise-sensitive areas, the tipping motion can be dampened to reduce impact and material discharge.
Automatic locking and position monitoring
Sensor-monitored locking and end-position control increase safety and automation potential during operation.
Stainless steel and ATEX-compliant versions available on request
Certified stainless steel and explosion-proof variants are available for hygienically sensitive or hazardous environments.
Advantages
JOEST tipping devices offer a robust and flexible solution for the ergonomic and safe emptying of a wide variety of containers. With high load capacities, variable drive technologies, and adaptable container interfaces, they deliver reliable performance in both manual and automated operations – compact, versatile, and built to last.
